ΕΚΤΥΠΩΤΗΣ

• Θερμικός 57mm
• Ταχύτητα εκτύπωσης 75mm/sec
• Εύκολη τοποθέτηση χαρτοταινίας (open/drop)
• Δυνατότητα εκτύπωσης γραφικών
• Μήνυμα στο τέλος της απόδειξης
• Εκτύπωση διπλού μεγέθους χαρακτήρων
• Συνδυασμός απλών και bold χαρακτήρων στην ίδια γραμμή



ΟΘΟΝΗ

• Οθόνη χειριστή και πελάτου LCD 2 γραμμών, 16 χαρακτήρων
• Λεπτομερής απεικόνιση συναλλαγής
• Δυνατότητα κυλιόμενου μηνύματος



ΠΛΗΚΤΡΟΛΟΓΙΟ

• 39 stroke πλήκτρα (12 αριθμητικά και 27 λειτουργικά)



ΛΕΙΤΟΥΡΓΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ

• 20 Τμήματα εμφανή με λειτουργία shift (συνολικά 50 Τμήματα)
• 20 Κατηγορίες
• 20.000 Είδη με σταθερή ή ελεύθερη τιμή και Barcode κωδικό
• Ανάλυση ΦΠΑ στην απόδειξη
• Αναγραφή σχολίων εντός απόδειξης



ΣΥΝΔΕΣΕΙΣ

• 1 USB (Σύνδεση με H/Y)
• 2 SERIAL (Σύνδεση με Ζυγό, πληκτρολόγιο, Display, EFTPOS,  barcode scanner)
• 1 ETHERNET (σύνδεση σε WEB server)
• 1 SD slot (για ηλεκτρονική μεταφορά αρχείων)
• 1 σύνδεση για συρτάρι



ΕΙΔΙΚΕΣ ΛEITOYPΓIEΣ

• Δυνατότητα διασύνδεσης με ERP μέσω χρήσης πρωτοκόλλου  επικοινωνίας, OPOS driver η fiscal driver
• Δυνατότητα χρήσης εστιατορίου



ANAΦOPEΣ

• Σύνολα ημέρας – Χ
• Ταμείο ημέρας
• Πωλήσεις ειδών
• Πωλήσεις τμημάτων ημέρας
• Σύνολο πωλήσεων τμημάτων
• Χειριστές
• Γενικοί παράμετροι
• Συγκεντρωτικά σύνολα
• Αναφορά κατηγοριών
• Στατιστικά
• Περιοδική με Ζ –Ζ
• Περιοδική με ημερομηνία
• Κλείσιμο Φ.Μ.
• Αποστολή ΦΜ – Η/Υ



ΔΙΑΣΤΑΣΕΙΣ

• Ύψος: 11cm
• Πλάτος:  31cm
• Μήκος: 22cm

ΒΑΡΟΣ
• 1,640 Κg

Λειτουργία με ρεύμα αλλά και με μπαταρία (option)
• Μέγεθος χαρτοταινίας 57mm

Τεχνικά Χαρακτηριστικά:
Τροφοδοσία:
• DC output - 9V ,  3A

Τμήματα/Είδη/Χειριστές:
• 15.000 είδη με κωδικό ή barcode
• Με σταθερή ή ελεύθερη τιμή
• 10 τμήματα (5χ2 επίπεδα)

Πρόσθετα χαρακτηριστικά:
• Πληκτρολόγιο - 30  πλήκτρα
• SD κάρτα μνήμης 8GB
• Προαιρετική μπαταρία μόλυβδου 7.4V 2,6Ah

Πεδίο τιμών θερμοκρασίας/υγρασίας:
• Θερμοκρασία λειτουργίας 5 °C - 45°C
• Θερμοκρασία αποθήκευσης -10 °C - +50°C

Θύρες:
• 1 serial (RJI0) (Σύνδεση με scanner, ζυγό,  εκτυπωτή ,  συρτάρι (6/12/volt)
• 1 USB (Σύνδεση με H/Y)
• 1 ETHERNET (Σύνδεση σε δίκτυο)
• 1 WIFI

Ειδικές Λειτουργίες:
• Προγραμματισμός από Η/Υ (CATPOS manager)
• Γραφικά (logo) στην αρχή της απόδειξης
• WiFi ( option )

Οθόνη:
• Οθόνη χειριστή 5 γραμμών, με back light
• Οθόνη πελάτη 2 γραμμών, με back light

Εκτυπωτές:
• Θερμικός, υψηλής αξιοπιστίας
• Tαχύτητα εκτύπωσης 100mm/sec
• Χαρτοταινία 57χ40mm
• Εύκολη εισαγωγή χαρτοταινίας (easy load)
• Διαστάσεις (Ύψος x Πλάτος x Μήκος): 5,8cm x 8,9cm x 22,3cm

Βάρος: 0,56 kg

ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Τεχνικά Χαρακτηριστικά
Τμήματα/Είδη/Χειριστές:
•20 τμήματα / 200 είδη (διαχείριση απεριορίστου αριθμού ειδών με διασύνδεση λογισμικού εφαρμογών)
•Ηλεκτρονικό ημερολόγιο διαφύλαξης αντιγράφων, εκδιδομένων δελτίων και ηλεκτρονική μεταφορά των δελτίων για αποθήκευση στον διασυνδεόμενο Η/Υ

Συνδέσεις:
•Σύνδεση με Η/Υ με USB, ETHERNET, SERIAL
•Σύνδεση με customer display
•Σύνδεση με συρτάρι

Λειτουργικό Σύστημα:
• 20 Τμήματα / 20 Κατηγορίες Διαχείριση Απεριόριστου Αριθμού Ειδών με διασύνδεση Λογισμικού Εφαρμογών Ηλεκτρονικό Ημερολόγιο διαφύλαξης αντιγράφων, εκδιδόμενων δελτίων και ηλεκτρονική μεταφορά των δελτίων για αποθήκευση στον διασυνδεόμενο H/Y
• Αποστολή αρχείου συναλλαγών (s.txt) σε WEB server

Ειδικές Λειτουργίες:
•Ταμειακό σύστημα εισόδου δεδομένων για έκδοση αποδείξεων λιανικής από Η/Υ ή σύστημα POS
•Διασύνδεση με ERP μέσω χρήσης πρωτοκόλλου επικοινωνίας, OPOS driver, Fiscal driver



Αναφορές:
•Δελτίο Χ κινήσεων
•Δυνατότητα ανεύρεσης και απεικόνησης σε Η/Υ παρελθόντων δελτίων λιανικής •Εκτύπωση των παραγόμενων δελτίων του ηλεκτρονικού ημερολογίου
•Ημερήσιο δελτίο Ζ - επανέκδοση αντιγράφου
•Περιοδικές αναφορές φορολογικής μνήμης

Οθόνη: LCD 2 γραμμών, απεικόνιση μενού επιλογών

Εκτυπωτές:
•Seiko LTP θερμικός 80mm
•Δυνατότητα εκτύπωσης γραφικών
•Εκτύπωση διπλού μεγέθους χαρακτήρων
•Εύκολη τοποθέτηση χαρτοταινίας
•Μήνυμα στο τέλος της απόδειξης
•Ταχύτητα εκτύπωσης 220mm/sec με αυτόματη κοπή (auto cutter)

Διαστάσεις: Ύψος: 14.5cm, Πλάτος: 16cm, Μήκος: 25cm
Βάρος: 1.970kg

ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
• Συμπαγές και κομψό
• Πολλαπλές διασυνδέσεις εισόδου – εξόδου (I/O) για τα περιφερειακά
• Ευέλικτη τοποθέτηση σε πάγκο ή τοίχο

Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής: J19 Intel® Celeron® J1900 Quad-Core / Intel® Core i3
• Οθόνη: 15" TFT LED Backlight - 1024 x 768 - Projective Capacitive Touch / 19" Wide Touch Screen
• Μνήμη: J19 4GB Standard, DDR3L 1600 MT/s, Socket 1 x SODIMM
• Σκληρός δίσκος: J19 SATA 2 (3Gb/s) 2.5 inch SSD 64GB, Support AHCI
• OS: Windows 7, Windows 8.1, Windows 10, POS Ready 7

Διασυνδέσεις:
• Οθόνη: 1 x VGA (With Power Output)
• USB: J19 6(Rear 2, Back 4, USB 2.0 x 6)
J19 3(Reserved for MSR, SCR, i-Button/Touch Controller/Camera), RJ-45
• Serial Port (Σειριακές θύρες) :
5 (COM 1 with 5V/12V Power Output on 9 Pins, BIOS)
(COM2~3 RJ-45 , Full Signal)
(COM5 Reserved for Cash Drawer Port)
(COM4 RJ-11, Only TX/RX, 12V Power Output, Reserved for 2x20 Customer Display)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
• LAN : 1 x Gigabit Ethernet, RJ-45



Τροφοδοσία: J19 Adaptor 12V, 5A
Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 60 ℃ at 10% to 90% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 80 ℃ at 10% to 90% humidity, non-condensing
• Διαστάσεις(W x H x D): 364 x 333 x 210 (mm), 14.3 x 13.1 x 8.2(in)



Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής:
Q3 Intel® Core™ i3-4100M Processor (3M Cache, 2.50 GHz), Fanless
Q4 Intel® Core™ i5-4210M Processor (3M Cache, up to 3.20 GHz), Fanless
Q5 Intel® Core™ i7-4600M Processor (4M Cache, up to 3.60 GHz), Fanless
J19 Intel® Celeron® J1900 (2.0 GHz) Quad-Core Processor, Fanless • Οθόνη:
15" TFT LED Backlight 1024 x 768 Projective Capacitive Touch
17" TFT LED Backlight 1280 x 1024 Projective Capacitive Touch

Μνήμη:
Qs 4GB Standard (Max. 16GB), DDR3L 1600 MT/s, Socket 1 x SODIMM (Max. 2 Optional)
J19 4GB Standard (Max. 8GB), DDR3L 1600 MT/s, Socket 2 x SODIMM
• Σκληρός δίσκος:
Qs SATA 3 (6Gb/s) 2.5 inch SSD 64GB, Support AHCI
J19 SATA 2 (3Gb/s) 2.5 inch SSD 64GB, Support AHCI
• OS: Windows 7, Windows 8.1, Windows 10, POS Ready 7

Διασυνδέσεις:
• Οθόνη: 1 x VGA (With Power Output)

USB:
Qs 8 (Rear 6 = USB 3.0 x 4, USB 2.0 x 2ㅣSide 2 = USB 2.0 x 2)
J19 8 (Rear 6 = USB 3.0 x 1, USB 2.0 x 5ㅣSide 2 = USB 2.0 x 2)
Qs/J19 3(Reserved for MSR, SCR, i-Button/Touch Controller/Camera), RJ-45



Serial Port (Σειριακές θύρες) :
6 (COM 1~2 with 5V/12V Power Output on 9 Pins, Jumper)
(COM3 with 5V/12V Power Output on 9 Pins, BIOS)
(COM4 Only TX/RX, 12V Power Output, Reserved for 2x20 Customer Display)
(COM5 Reserved for Cash Drawer Port)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
• LAN : 2 x Gigabit Ethernet, RJ-45

Τροφοδοσία: Adaptor 24V, 5A
Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 50 ℃ at 10% to 80% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 80 ℃ at 10% to 80% humidity, non-condensing
• Διαστάσεις(W x H x D): 364 x 382 x 344(mm), 14.3 x 15 x 13.5(in)



Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής:
Q3 Intel® Core™ i3-4100M Processor (3M Cache, 2.50 GHz), Fanless
Q4 Intel® Core™ i5-4210M Processor (3M Cache, up to 3.20 GHz), Fanless
Q5 Intel® Core™ i7-4600M Processor (4M Cache, up to 3.60 GHz), Fanless
J19 Intel® Celeron® J1900 (2.0 GHz) Quad-Core Processor, Fanless

Οθόνη:
15" TFT LED Backlight 1024 x 768 Projective Capacitive Touch
17" TFT LED Backlight 1280 x 1024 Projective Capacitive Touch

Μνήμη:
Qs 4GB Standard (Max. 16GB), DDR3L 1600 MT/s, Socket 1 x SODIMM (Max. 2 Optional)
J19 4GB Standard (Max. 8GB), DDR3L 1600 MT/s, Socket 2 x SODIMM

Σκληρός δίσκος:
Qs SATA 3 (6Gb/s) 2.5 inch SSD 64GB, Support AHCI
J19 SATA 2 (3Gb/s) 2.5 inch SSD 64GB, Support AHCI
• OS: Windows 7, Windows 8.1, Windows 10, POS Ready 7

Διασυνδέσεις:
• Οθόνη: 1 x VGA (With Power Output)



USB:
Qs 8 (Rear 6 = USB 3.0 x 4, USB 2.0 x 2ㅣSide 2 = USB 2.0 x 2)
J19 8 (Rear 6 = USB 3.0 x 1, USB 2.0 x 5ㅣ Side 2 = USB 2.0 x 2)
Qs/J19 3(Reserved for MSR, SCR, i-Button/Touch Controller/Camera),RJ-45

Serial Port (Σειριακές θύρες) :
6 (COM 1~2 with 5V/12V Power Output on 9 Pins, Jumper)
(COM3 with 5V/12V Power Output on 9 Pins, BIOS)
(COM4 Only TX/RX, 12V Power Output, Reserved for 2x20 Customer Display)
(COM5 Reserved for Cash Drawer Port)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
• LAN : 2 x Gigabit Ethernet, RJ-45

Τροφοδοσία:
Qs Adaptor 24V, 5A
J19 Adaptor 12V, 5A

Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 50 ℃ at 10% to 90% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 90 ℃ at 10% to 80% humidity, non-condensing
• Διαστάσεις (W x H x D): 364 x 382 x 344(mm) 14.3 x 15 x 13.5(in)



Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής:
Qs 2nd, 3rd, 4th Generation Intel®Core™ i7, i5, i3 Processors
D25 Intel®Atom®D2550 (1.86 GHz) Dual-Core Processor, Fanless

Οθόνη:
15" TFT LED Backlight 1024 x 768 Projective Capacitive Touch
17" TFT LED Backlight 1280 x 1024 Projective Capacitive Touch

Μνήμη:
Qs 4GB Standard (Max. 8GB), DDR3 1600MT/s, Socket 1 x SODIMM (Max. 2 Optional)
D25 4GB Standard, DDR3L 1066MT/s, Socket 1 x SODIMM (Max.4GB)

Σκληρός δίσκος:
Qs SATA 3 (6Gb/s) 2.5 inch HDD 320GB, SSD 64GB or 32GB (Max. 2 Optional), Support AHCI
D25 SATA 2 (3Gb/s) 2.5 inch SSD 32GB, SSD 64GB or 32GB, HDD 320GB (Max.2 Optional), Support AHCI
• OS: Windows XP/Vista, Windows 7, POS Ready 2009/7

Διασυνδέσεις:
• Οθόνη: 1 x VGA (With Power Output)
• USB:
Qs 6 (Rear 6 = USB 3.0 x 4, USB 2.0 x 2)
D25 4 (Rear 4 = USB 2.0 x 4)
Qs/D25 2(Reserved for MSR, SCR, i-Button/Touch Controller), RJ-45



Serial Port (Σειριακές θύρες) :
6 (COM 1~2 with 5V/12V Power Output on 9 Pins, Jumper)
(COM3 with 5V/12V Power Output on 9 Pins, BIOS)
(COM4 Only TX/RX, 12V Power Output, Reserved for 2x20 Customer Display)
(COM5 Reserved for Cash Drawer Port)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
• LAN :
Qs 2 x Gigabit Ethernet, RJ-45
D25 1 x Gigabit Ethernet, RJ-45

Τροφοδοσία:
Qs Adaptor 24V, 5A
D25 Adaptor 12V, 5A

Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 50 ℃ at 10% to 90% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 90 ℃ at 10% to 80% humidity, non-condensing
•Διαστάσεις (W x H x D): 364 x 382 x 344(mm) 14.3 x 15 x 13.5(in)



Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής:
Intel® Celeron® J1900 (2.0 GHz) Quad-Core Processor, Fanless
Intel® Celeron® J1800 (2.41 GHz) Dual-Core Processor, Fanless

Οθόνη:
8" Wide TFT LCD, LED Backlight 1024x600, Projective Capacitive Touch
9.7" Wide TFT LCD, LED Backlight 1024x768, Projective Capacitive Touch

Μνήμη:
2GB Standard, DDR3L 1600 MT/s, Socket 1xSODIMM

Σκληρός δίσκος:
mSATA (3Gb/s) SSD 64GB, Support AHCI
• IOS: Windows 7, Windows 8.1, Windows 10 IoT Enterprise, POS Ready 7

Εκτυπωτής:
3" Jam-Free Thermal, 200-250 mm/s
Auto Cutter (Interface:Serial,USB), Built-in Type



Διασυνδέσεις:
• USB:
4 (Rear 4, USB 3.0 x 2, USB 2.0 x 2)
• Serial Port (Σειριακές θύρες) :
COM 1, COM 2, COM 3
• LAN :
1 x Gigabit Ethernet

Τροφοδοσία:
Adaptor 24V, 2A

Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 60 ℃ at 10% to 90% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 80 ℃ at 10% to 90% humidity



Processor family:
Intel® Core™ i3 processor

Chipset:
Intel® Q170

Form factor:
All-in-one

Environmental:
Low halogen
Memory

Memory, standard:
4 GB DDR4-2133 (1 x 4 GB)

Memory Slots:
2 SODIMM
Storage

Internal drive bays:
One 2.5"; Two M.2

Internal Storage:
128 GB SATA SSD
Graphics

Graphics:
Intel® HD Graphics
Expansion Features



Ports
Display Head (bottom):
1xaudio-in
1xaudio-out
1xDisplayPort™ 1.2
1xRJ-45
2xRS-232
2xUSB 2.0
2xUSB 3.0
3xPowered 12 Volt USB
1xPowered 24 Volt USB
1xcash drawer
Display Head (top, left, right):
3 USB for peripheral integration

Display:
15.6" diagonal HD anti-glare touch screen (1366 x 768)

Expansion slots:
1 M.2 2230



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Form Factor: All-in-one
Operating System: Windows Embedded 8.1 Industry Pro Retail 64-bit
Windows 8.1 Pro 64-bit
Windows Embedded POS Ready 7 32-bit
Windows Embedded POS Ready 7 64-bit
Windows 7 Professional 32 (available through downgrade rights from Windows 8.1 Pro)
Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro)
FreeDOS 2.0

Display: 14"diagonal wide-aspect display with 5-wire resistive touch technology
Processor: Intel® Celeron® J1900 with Intel HD Graphics (2.00GHz, 2 MB cache, 4c ores)
Chipset: Chipset integrated on processor
Memory: Up to 8GB 1333 MHz DDR3 SDRAM
Internal Storage: 320 GB up to 500 GB SATA (7200rpm)
Up to 500 GB SATA SED
32 GB up to 64 GB SATA SSD
128 GB up to 256 GB SATA SE SSD



Graphics: Integrated Intel HD Graphics
Audio: DTS Studio Sound audio management technology with line-out/ head phone and line-in/ microphone ports on I/O panel. Two internal speakers on display head
Communications: HP 802.11a/b/g/n (2x2) Wireless Dual Band Mini Card with Bluetooth® (optional)
Ports and Connectors: 4 RJ-50 (power configurable); 1 USB 3.0; 3 USB 2.0; 3 USB 2.0 (on display); 1 powered 12V USB; 1 powered 24V USB; 1 cash drawer; 1 Display Port; 1RJ-45 Available options include RJ-50 to DB9 adapter cables (either 1 meter or 2 meters in length)
Security Management: HP Keyed Cable Lock Kit (optional)
Dimensions: 35.59 x 22.53 x 36.62cm
Weight: 6.83kg with stand

Energy Efficiency: ENERGYSTAR® qualified; EPEAT® Gold registered
Power: 180 W 89% efficient, active PFC
Warranty: 3-year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Form Factor: All-in-one
Operating System: Windows Embedded 8.1 Industry Pro Retail 64-bit
Windows 8.1 Pro 64-bit
Windows Embedded POS Ready 7 32-bit
Windows Embedded POS Ready 7 64-bit
Windows 7 Professional 32 (available through downgrade rights from Windows 8.1 Pro)
Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro)
FreeDOS 2.0

Display: 14" diagonal wide-aspect display with projected capacitive touch technology
Processor: Intel® Pentium® J2900 with Intel HD Graphics (2.41 GHz, 2 MB cache, 4 cores)
Chipset: Chipset integrated on processor
Memory: Up to 8GB 1333 MHz DDR3 SDRAM
Internal Storage: 320 GB up to 500 GB SATA (7200rpm)
Up to 500 GB SATA SED
32 GB up to 64 GB SATA SSD
128 GB up to 256 GB SATA SE SSD



Graphics: Integrated Intel HD Graphics
Audio: DTS Studio Sound audio management technology with line-out/ head phone and line-in/ microphone ports on I/O panel. Two internal speakers on display head
Communications: HP 802.11a/b/g/n (2x2) Wireless Dual Band Mini Card with Bluetooth® (optional)
Ports and Connectors: 4 RJ-50 (power configurable); 1 USB 3.0; 3 USB 2.0; 3 USB 2.0 (on display); 1 powered 12V USB; 1 powered 24V USB; 1 cash drawer; 1 Display Port; 1RJ-45 Available options include RJ-50 to DB9 adapter cables (either 1 meter or 2 meters in length)
Security Management: HP Keyed Cable Lock Kit (optional)

Dimensions: 35.59 x 22.53 x 36.62cm
Weight: 6.83kg with stand
Energy Efficiency: ENERGYSTAR® qualified; EPEAT® Gold registered
Power: 180 W 89% efficient, active PFC
Warranty: 3-year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Main board: IAT1-1037
CPU: Intel Celeron 1037U 1.8 GHz Dual core
Chipset: Intel NM70 Chipset
Main Memory: 1GB DDRIII RAM
Display Size: 15’’ LCD with touch panel
Display Resolution: 1024x768

Touch Panel: 5 wire resistive touch
HDD: 2.5’’ SATA HDD 320G
Expansion slot: 1 x Mini PCIe
OS Support: POSReady 2009, POSReady 7, Windows XP/XPE, Windows 7,Windows 8, Linux
Power: AC 100V~240V / 60W Power Adapter
External I/O Interface

Serial Port: 4 x External COM Port with 5V / 12V selectable
Cash Drawer Port: 1 x RJ 11 with DC 12V, 1 x RJ 11 with DC 24V
Keyboard Port: 1 x PS/2
VGA Port: 1 x VGA (DB15)
Audio Port: 1 x Line in, 1 x Line out

Speaker: 2 x Integrated 1.5 W stereo speaker
Ethernet Port: 1 x RJ45 10M / 100M / 1G Base-T
Parallel Port: 1 x Bi-directional Parallel (Standard)
USB Port: 4 x USB 2.0 Type A, 5 x USB 2.0 Type A
DC Output: 1 x 12V / 2.5A DC Jack
Power Button: 1 x power on/ off switch



Printer
Printing Method: Direct Thermal Printing
Total dots per line: 576 dots
Dot density: 8 dots / mm
Paper width: 80 mm
Printing width: 72 mm
Printing speed: 180 mm / s
Paper loading type: Drop-in easy loading
Paper feeding pitch 0.0625mm

Optional Peripheral
Magnetic Card Reader: ISO 7811 option 1 / 2 / 3 track
Finger Print: 512dpi x 8bit gray scale, Capture area; 14.6 x 18.1 mm
i-button: Dallas Key
Wireless LAN: 802.11 b / g
Customer Display: VFD / LCD Customer Display
Second Display: LCD Display / non-Touch

Environment
EMC & Safety: CE / FCC Class A
Operating Temperature: 5oC – 40oC
Storage Temperature: -20oC – 60oC
Operating Humidity: 15% - 80% RH
Storage Humidity: 20% - 90% RH

Mechanical
Housing Color Black
Construction ABS + SECC
Dimension (W x D x H) 355 x 240 x 390 mm
Weight (N.W.) 7.1 Kg



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Οθόνη

Μέγεθος:
15" TFT LED Backlight
17" TFT LED Backlight

Ανάλυση:
15" 1024 x 768
17" 1280 x 1024

Φωτεινότητα:
15" 300cd/㎡ (typ.)
17" Max. 300cd/㎡ (typ.)

Γωνία θέασης:
15" 80°/80°/80°/80° (Typ.)
17" 85°/85°/80°/80° (Typ.)
Οθόνη Touch

Τύπος:
15" Projective Capacitive Touch
17" Projective Capacitive Touch

Διασυνδέσεις
• VGA: 1
• USB (A Type) 2
• USB (B Type) 1
• MSR 1 (RJ-45 for MSR, SCR, i-Button)
• Audio 1 (Mic-in)



Τροφοδοσία
• Τροφοδοτικό Adapter 12V, 3A

Φυσικά χαρακτηριστικά - Περιβάλλον
• Διαστάσεις (W x H x D):
15" 364 x 345 x 217(mm)
14.3 x 13.5 x 8.5(in)
17" 392 x 376 x 217(mm)
15.4 x 14.8 x 8.5(in)
• Καθαρό Βάρος: 5600g, 12.3lbs

Περιφερειακά:
• Τύπος: 15" 5-Wired Resistive Touch
• Στήριξη τοίχου: VESA-Compatible, 100 x 100(mm)



Contrast Ratio 700/1
Brightness 300cd/m²
Viewing Angle 150/135
Response Time 8ms
Touch Panel 17", 5-wire
Outside Dimension 294.5mm*366mm
viewing area 240mm*324mm
Active area 240mm*324mm
Surface　Hardness 3H
Optical　 Clarity 80+%
Operating　Temperature -10C ~60C
Endurance　Test 　strikes Over 10 millions
Operating　Voltage DC5V
Resistance 200Ω~900Ω
Linearity 1.50%



Faceplate　Surface Anti-glare　coating, glare coating
Film Thickness 0.175mm, 0.188mm
Glass Thickness 0.7mm, 1.1mm,1.8mm
Operation　Pressure 20~150g
Storage　Temperature -30~80 deg C
Message　Noise 5m sec ~ 15m sec
Operating　Current 5mA~25mA
Humidity <95%
Isolation　Resistance 20+MΩ@ DC25V
Sealable against dust ,water, oil , static



Touch Panel 15"" 5-wire
Outside Dimension 247mm×322mm
Viewing area 235mm×310mm
Active area 228mm×304mm
Surface Hardness 3H
Optical Clarity 80%
Operating Temperature -10C ~60C
Endurance Test strikes Over 10millions
Operating Voltage DC5V
Resistance 200Ω~900Ω
Linearity 1.50%
Faceplate Surface Anti-glare coating，glare coating
Film Thickness 0.175mm, 0.188mm
Glass Thickness 0.7mm, 1.1mm,1.8mm



Operation Pressure 20~150g
Storage Temperature -30℃ ~80 ℃
Operating Current 5mA~25mA
Humidity <95%
Isolation Resistance 20MΩ ＠ DC25V
Sealable against Dust ,water, oil , static
Operation Pressure 20~150g
Storage Temperature -30℃ ~80 ℃
Operating Current 5mA~25mA
Humidity <95%
Isolation Resistance 20MΩ ＠ DC25V
Sealable against Dust ,water, oil , static



Τεχνικά Χαρακτηριστικά:
• Επεξεργαστής:
Qs 2nd, 3rd, 4th Generation Intel® Core™ i7, i5, i3 Processors
J19 Intel® Celeron® J1900 (2.0 GHz) Quad-Core Processor, Fanless

Μνήμη:
Qs 4GB Standard (Max. 8GB), DDR3 1600MT/s, Socket 1 x SODIMM (Max. 2 Optional)
J19 4GB Standard, DDR3L 1600 MT/s, Socket 1 x SODIMM

Σκληρός δίσκος:
Qs SATA 3 (6Gb/s) 2.5 inch HDD 320GB, SSD 64GB or 32GB (Max. 2 Optional), Support AHCI
J19 SATA 2 (3Gb/s) 2.5 inch SSD 64GB, Support AHCI

IOS: Windows 7, Windows 8.1, Windows 10, POS Ready 7

Διασυνδέσεις:
• Οθόνη: 1 x VGA (With Power Output)
• USB:
Qs 6 (Rear 6 = USB 3.0 x 4, USB 2.0 x 2)
4 (Rear 4 = USB 3.0 x 2, USB 2.0 x 2)
J19 6 (Rear 6 = USB 3.0 x 1, USB 2.0 x 5)



Serial Port (Σειριακές θύρες) :
3 (COM 1 ~ 3 with 5V/12V Power Output on 9 Pins)
• LAN : 2 x Gigabit Ethernet, RJ-45

Τροφοδοσία:
Qs Adaptor 24V, 6A
J19 Adaptor 12V, 5A

Περιβαλλοντικά και Φυσικά Χαρακτηριστικά:
• Θερμοκρασία λειτουργίας: 0 ℃ ~ 40 ℃ at 10% to 80% Humidity
• Θερμοκρασία αποθήκευσης: -20 ℃ ~ 80 ℃ at 10% to 90% humidity, non-condensing
• Διαστάσεις(W x H x D): 280 x 78 x 355(mm), 11 x 3 x 13.9(in)



Display: 9.4cm (3.7inches) Blanview ® Color LCD with Touch Panel
Resolution VGA: (480 x 640 dots) 65,536 colors
Printer Printing Method: Thermal line dot
Paper Width: 80 mm or 58 mm
Printing Width: 72 mm or 48 mm

NFC Reader
Writer Frequency: 13.56MHz
Contactless Smart Card: ISO14443 Type A(MIFARE ®) / ISO14443 Type B / Felica ®
RFID Tag: ISO15693 (I •CODE ® SLI / Tag-it ® / my-d ®)
Touch Panel: Plastic panel (resolution 480 × 640 dots) with character input pad
Interface: Serial USB (Host, Client) × 1
Card Slot: SDIO (SDHC supported) × 1
Audio Microphone: Built-in (monaural), Speaker: Built-in (monaural)



Power Main: Power Lithium-ion battery pack (Operating period: Approx. 20 hours and more*)
* When 120 keyboard inputs made every 10 minutes
Memory Backup: Lithium battery (rechargeable) on board
Charge Time: Approx. 5 hours

Environment: Dust/Splash-proof IP54 (compliant with IEC60529 standard)
Drop Durability: 1.5m
Operating Temperature: -20°C to +50°C



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
• CPU: Marvell® PXA320, 806 MHz
• Operating System: Microsoft® Windows® Embedded Compact 7 (english version)
• Memory
• RAM: 256 MB
• ROM: 512 MB
• Display
• Size: 2,4 inch (61 mm) diagonal
• Resolution: 240 x 320 pixels, QVGA, 65.536 colours
• Technology: TFT colour LCD with LED backlight
• 2 LED Indicators: 1: Battery charging status (red, orange, green), 2: Communication/ scan/ application status
•

Input
• Keyboard: 10 numeric keys with phone keypad characters, 8 function keys (4 colored), Enter key, Cursor keypad, CLR key, ▲key, ▼key, On-/Off key
• Scan Trigger: 3 large scan release buttons (center, left and right)
• Wireless Communication
• WLAN: IEEE 802.11 a/b/g/n (max. 65 Mbit/s), security standard and encryption WPA2/AES
• Bluetooth™: Version 2.1 + EDR (max. 2,169.6 kbit/s date rate), backward compatible to version 2.0 and 1.2

Interfaces
• Infrared: SIR printer interface
• USB Contacts: Version 1.1 (Host / Client), USB connection only with docking station
• Audio: Built-in microphone (mono) and speaker for signals and alarms etc.
• Vibrating Signal: Confirms successfully decoded ident codes
• Optoelectronic Ident Code Reader
• Model: Scanner (DT-X100-10E), Imager (DT-X100-20E)
• Type: Laser diode, scan rate approx. 100/s (DT-X100-10E), CMOS Imager, 832 x 640 px (DT-X100-20E)
• Resolution: Barcodes: 0.127 mm, Stacked: 0.127 mm (DT-X100-10E), Barcodes: 0.15 mm, Stacked: 0.168 mm, Matrix: 0.25 mm (DT-X100-20E)
• Reading Distance: Approx. 40 to 550 mm (DT-X100-10E), From a distance of a few millimeters to several meters, depending on size and print quality of the ident code (DT-X100-20E)
• Aimer: Laser beam 650 +10/-5 nm, 1 mW or less (DT-X100-20E)
• Readable 1D Symbologies: EAN-8, EAN-13, UPC-A, UPC-E, ITF 2/5-Interleaved, Codabar (NW-7), Code32, Code39, Code93, Code128, GS1-128 (UCC/EAN128), MSI, ISBT, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar Expanded und 2/5-Industrial (only laser scanner version)
• Readable 2D Stacked-Codes (stacked 1D-Codes): GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked (DT-X100-10E), GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, PDF417, Micro PDF, Composite, Codablock F (DT-X100-20E)
• Readable 2D Matrix-Codes: DataMatrix, Maxicode, QR-Code, Aztec-Code, Micro QR (DT-X100-20E)



Power
• Operation: 3.7 V lithium-ion battery pack, standard: 1,100 mAh (for approx. 10 to 15 hours operating time), large: 1,880 mAh (for approx. 15 to 25 hours operating time)
• Memory Backup: Integrated lithium-ion battery

Environment
• Drop Durability: Drop height: 1.50 m onto concrete (1.0 m without bumper)
• Dust / Water Durability: IP54 protection class, IEC 60529 compatibel (protection against ingress of dust and splashing water on all sides)
• Operating Environment: Temperature range –20 to +50 °C, relative humidity 10 to 80 % (no condensation)
• Dimensions (W x H x D): 51 x 169 x 30 mm (basic device size, without bumper)
• Weight: Approx. 165 g with standard battery, approx. 185 g with large battery



Display
• Size: 2.7 inches (69 mm) diagonally
• Resolution: 240 x 320 pixels, QVGA, 65,536 colours
• Technology: Blanview® TFT colour LCD with LED backlighting and touchscreen
• Dual LED display: 1: Charge of battery (red, orange, green); 2: Communication/scan/application status

Input
• Keyboard: 10 alphanumeric keys, 8 function keys (4 displayed in colour), Enter key, cursor keypad, CLR key, L key, R key (all with backlighting), on/off button
• Initiating scanning: 3 large scanning buttons (centre, left and right)
• Touchscreen: Resistive touchscreen with scratch-resistant surface
• Wireless Communication
• WLAN: IEEE 802.11 a/b/g/n (max. 65 Mbit/s), WPA2/AES security standard and encryption
• Bluetooth™: Version 2.1 + EDR (up to 2,169.6 kbit/s data rate), backwards compatible with version 2.0 and 1.2

Interfaces
• Memory card slot: Compatible with microSD memory cards (SDHC)
• Expansion port: Electrical and mechanical connection for external hardware modules
• USB contacts: Version 1.1 (Host/Client), USB connection only available via docking station or adapter
• Audio: Built-in microphone (mono) and speaker for signals and audio warnings etc.
• Vibrating alert: To confirm correctly decoded identification codes
• Contactless SmartCard reader/writer



Power supply
• Operation: 3.7 V lithium-ion battery, 2,860 mAh (for around 20 to 25 hours of operating time)
• Storage protection: Built-in lithium-ion battery

Ambient conditions
• Protection against water/dust: IP67 protection class, IEC 60529-compatible (dust-proof and water-resistant against temporary immersion)
• Operating environment: Temperature range -20 to +50°C, relative humidity 10 to 90% (no condensation)
• Dimensions (width x height x depth): Approx. 66 x 187 x 33 mm (device measurement), depth at scanning head approx. 42 mm, 45 mm for All-Range
• Weight: Approx. 285 g (with standard battery)
• Drop resistance: Drop height: 3.0 m onto concrete



ENVIRONMENTAL
Operating Temperature: -10°C to +50°C (+14°F to +122°F)
Storage Temperature: -20°C to +60°C (-4°F to +148°F)
Humidity: 10% to 90% (non-condensing)
Drop: Multiple 1.2 m (4 ft) drops to concrete under room temperature
Tumble: 200 times at 0.5 m (1.64 ft)
ESD: ±8 kV Direct; ±12 kV Air
Environmental Sealing: IP54
Vibration: Vertical rms = 1.04 g, Transverse rms = 0.2 g, Longitudinal rms = 0.74 g

SYSTEM ARCHITECTURE
Processor: Qualcomm Snapdragon 410 MSM8916 1.2 GHz quad-core
Memory: 2 GB RAM, 8 GB Flash
Operating System: Android 4.4.4
Default Language: Worldwide English
Storage Expansion: MicroSDHC (up to 32 GB)
Battery: Li-Ion, 3.8 V, 4000 mAh
Button Batteries: 22 mF super-cap
Real-Time Clock: 10 min backup via super-cap
Charging Time: 4 hours
Battery Runtime: 12 hours
Scan Notification: Red/Green light
Radio Co-Location: All radios operate simultaneously
Scan Engine: HI2D Imager
Camera: 5.0-megapixel color camera with autofocus and LED flash
LEDs: Battery Condition: Red/Green/Blue
Warranty: One-year factory warranty



WIRELESS CONNECTIVITY
WLAN: EEE 802.11 a/b/g/n radio
NFC
Bluetooth® Class 4.0

ACCESSORIES Single Charging Cradle
Hand Strap
Replacement Battery
USB Communication Cable: Micro USB 2.0 (communicates to PC, supports adaptor/ USB charging)
USB Wall Adaptor: 5V/2A



ENVIRONMENTAL
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Humidity: 5 to 95% relative humidity (non-condensing)
Drop: Designed to withstand multiple 1.2 m (4 ft) drops to concrete
Tumble: Designed to withstand up to 800 (0.5 m) tumbles per IEC 60068-2-32 specification
ESD: +/- 15KV Air and +/- 8KV Contact
Environmental Sealing: Independently certified to meet IP54 standards for moisture and particle intrusion

SYSTEM ARCHITECTURE
Processor: TI AM3715 CortexA8 800 MHz
Operating System: Microsoft® Windows® Embedded Handheld 6.5
Memory: 256 MB RAM x 512 MB FLASH
Display: 7.1 cm (2.8 in) color LCD QVGA (240 x 320)
Touch Panel: 4-wire resistive touch panel and support for finger touch and stylus
Keypad: Standard keyboards: 46-key QWERTY or 30-key Numeric, dedicated scan key, volume up and down keys, side scan key, hard-reset key
Audio: Speaker, HAC receiver, microphone
I/O Ports: I/O connection(USB2.0,RS232,DC charging), Micro USB 2.0, 3.5 mm headphone/mic combo jack
Camera: 5.0 mega pixel camera with autofocus and flash
Storage Expansion: User accessible microSD slot (SDHC compatible). Please check with your Honeywell representative for available qualified card options.
Battery: Li-ion 3.7 V, 3340 mAh
Hours of Operation: 13 hours (decoding and sending data over WLAN every 9 seconds) 7.5 hours (decoding and sending data over WWAN every 15 seconds, GPS continuously receiving data)
Decode Capabilities: Dedicated imager capable of decoding standard 1D and 2D bar code symbologies
Development Environment: Honeywell SDK for Microsoft® Windows® Embedded Handheld 6.5
HSM Application Software: Honeywell Powertools® and Demos, Remote MasterMind™ for Mobility remote device management
Warranty: 1 year factory warranty



WIRELESS CONNECTIVITY
WWAN: Multi-mode UMTS/HSPA+ and GSM/GPRS/EDGE operation HSPA 3GPP (DL: 14.4Mbps, UL: 5.7Mbps) with GPS Bands supported:
• PHS8-US:
- Dual band 850/1900MHz GSM/GPRS/EDGE
- Dual band 850/1900MHz UMTS/HSPA+
• PHS8-E:
- Dual band 900/1800/GSM/GPRS/EDGE
- Dual band 900/2100MHz UMTS/HSPA+
• PHS8-P:
- Quad band 850/900/1800/1900/GSM/GPRS/EDGE
- 800/850/900/1900/2100MHz UMTS/HSPA+
WLAN: IEEE 802.11 b/g/n; WiFi™ certified

WLAN Security
• DeviceScape Supplicant
• WEP, 802.1x, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPA-PSK, WPA v2.0, and PEAP
WPAN: 2.4 GHz (ISM Band), Bluetooth® v2.1+EDR; 10 m (33 ft) line of sight



General Info
Appearance: Candy Bar Type
Dimension: 156x80x13.2mm
Weight: 220g

Hardware Info
Qualcomm Chipset: MSM8909-2, Quad core 1.1GHz
Screen: 5.0"" HD IPS
Resolution: 720X1280
Touch panel: CTP (G+F)
SIM card slot: Dual MINI SIM
GSM: 850/900/1800/1900MHz（0ptional)
WCDMA: 2100/1900 /900/850MHz（0ptional）
FDD Band: 1/2/3/4/5/7/8/19/17/20（0ptional）

Memory
ROM 8G
RAM 1G

Camera
Front camera: 2mp
Back camera: 8mp (interpolation1300W) Support digital zoom
Data communication
Bluetooth: Yes, BT4.0 (BR/EDR+BLE）
Wifi: Yes IEEE 802.11 b/g/n
NFC: No
PTT: No
FM: Yes
USB disk: Yes
Memory Card: Micro-SD, Up to 128G

Sensor
Acceleration Sensor: Yes
Gyro-Sensor: No
The distance/light sensor: Yes
Geomagnetic sensor: Yes
Air pressure sensor: No



Other
GPS: Yes
AGPS: Yes
BDS: No
Touch: Shared with flashlight
Loudspeaker: Class D power amplifier

Keypad
Function Key:
3 keys a) menu key b) back key c) home key,

Battery
Capacity: 3100 mAh Li-ion battery
Interface
USB: Micro USB 5pin
Earphone: 3.5mm
Charger: USB port

Language
Default: Yes Multinational
Call Function
Scene: Yes

Multimedia
Media Player: (MP3、MP4) Yes
VPN: Yes
Recording: Yes
Stereo headset: Yes
MP3 Audio-format: MP3,MIDI,AMR,AAC,WAV
MP3 Lyrics synchronous: Yes
MP4 Video-format: 3GP,MP4,AVI,MJPG



SCANNER ΠΑΓΚΟΥ (ΧΩΝΕΥΤΟ) - ΠΟΛΥΔΕΣΜΙΚΟ LASER SCANNER
HONEYWELL HORIZON MS7600

Επιτραπέζιο Scanner Laser 1D

ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
O P E R AT I O N A L
Light Source: Visible Laser Diode 650 nm + 10 nm
Laser Power: 1.1 mW (peak)
Depth of Scan Field: 0 mm - 203 mm (0” - 8.0“) for 0.33 mm (13 mil) bar code
Width of Scan Field: 137 mm (5.4”) @ 40 mm (1.6”) ; 221 mm (8.7”) @ 178 mm (7.0”)
Scan Speed: 2000 scan lines per second
Scan Pattern: 5 fields of 4 parallel lines (omnidirectional)
Number of Scan Lines: 20
Minimum Bar Width: 0.127 mm (5.0 mil)
Decode Capability: Autodiscriminates all standard bar codes;
for other symbologies call Metrologic
System Interfaces: PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation,
IBM 468x/469x, Stand Alone PC Keyboard, USB
Print Contrast: 35% minimum reflectance difference
Number Characters Read: Up to 80 data characters
Roll, Pitch, Yaw: 360°, 60°, 60°
Beeper Operation: 7 tones or no beep
Indicators (LED): Amber = laser on, ready to scan; Red = good read, decoding



M E C H A N I C A L
Dimensions: 193 mm H x 88 mm D x 229 mm W (7.6” H x 3.5” D x 9.0” W)
Weight: 2.88 kg (6.35 lbs)
Termination: Three 10-pin modular RJ45
Cable: Standard 2.1 m (7’) straight; for other cables call Metrologic

E L E C T R I C A L
Input Voltage: 5.2 VDC + 0.25 V
Power: 2.6 W
Operating Current: 500 mA
DC Transformers: Class II; 5.2 VDC @ 650 mA
Laser Class: IEC 60825-1:1993 + A1:1997 + A2:2001 Class 1
EMC: FCC, ICES-003 & EN55022 Class A

E N V I R O N M E N TA L
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 60°C (-40°F to 140°F)
Humidity: 5% to 95% relative humidity, n o n - c o n d e n s i n g
Light Levels: Up to 4842 Lux (450 footcandles)
Contaminants: Sealed to resist airborne particulate contaminants
Ventilation: None required



ELECTRICAL
Input Voltage: 12 VDC ± 0.5 VDC
Operating Power: 10.2W (850mA @ 12vDC)
Standby Power: 4.9W (410mA @ 12vDC)
Host System Interfaces: USB, RS232, IBM 46xx (RS485)
Peripheral Interface: 2x USB, 1x RS232, Scale Display, Composite Video, EAS
Camera Output Power: 3.6W (300mA @ 12VDC)

INDICATORS
LEDs:
Top Indicator Bar: Dim Green: laser on, ready; Bright Green Flash: good read; Blue: EAS DeactivateFront: Amber: Scale at Zero
Diagnostic Display: Full text diagnostic display

ENVIRONMENTAL
Operating Temperature: 10°C to 40°C (50°F to 104°F)
Storage Temperature: -40°C to 70°C (-40°F to 140°F)
Humidity: 5% to 95% relative humidity, non-condensing
Environmental Sealing: IP42
Light Levels: 0 to 80,000 lux (7,432 foot-candles)



SCAN PERFORMANCE
Scan Technology:
Hybrid: Omnidirectional Laser + Area Image
Sides Read / Scan Zone: 6 / 360

Scan Pattern:
Laser: 192 total scan lines; Imager: VGA Image
Scan Speed: [21,500 scan lines
Resolution: 1D: 4 mil; 2D: 6.7mil
Print Contrast: 25%
Decode Capability: Reads standard 1D, GS1 Databar and 2D symbologies
Warranty: 2 year factory warranty



Βασικά Χαρακτηριστικά:
• Εύκολη εγκατάσταση χαρτοταινίας
• Εύκολη συντήρηση
• Δυνατότητα εκτύπωσης barcode

Τεχνικά Χαρακτηριστικά:
Ταχύτητα εκτύπωσης: 220 mm/sec
Πλάτος εκτύπωσης: Έως 72mm
Διάμετρος εκτύπωσης: 58mm ή 80 mm
Ανάλυση: 203dpi (8dots/mm)
Βάρος: 1.37 kg
Θερμοκρασία λειτουργίας: 0 – 40℃
Θερμοκρασία αποθήκευσης: -20 - 60℃
Επίπεδα υγρασίας: 10-80%
Διαστάσεις (L x W x H) 198 x 145 x 146 mm
Εγγύηση: 2 year
Διασυνδέσεις: Τριπλή διασύνδεση
Cutter: Full or Partial Cut



Διαθέσιμα software:
Emulation
BXL / POS
Driver / Utility
Windows Driver, OPOS Driver, JPOS Driver, Linux CUPS Driver, Mac Driver, Virtual COM USB/Ethernet Driver, Utility Program
SDK
iOS SDK, Android SDK



Media Characteristics
Media Type: Receipt
Media Width: 80 mm Optional 58 mm (with 2 inch Partition)
Media Roll Diameter: Up to 83 mm
Media Thickness: 0.062 ~ 0.075 mm
Supply Method: Easy Paper Loading

Physical Characteristics
Dimensions (W x L x D): 145 x 204 x 146 mm (5.70 x 8.03 x 5.74 inch)
Weight: 1.55kg (3.41 lbs)

Power:
EnergyStar Certified
External Power Adaptor 100-240V AV, 50/60Hz
Drawer Port: 2 ports (via y-type adaptor)
Performance Characteristics

Memory:
64 Mbit SDRAM
32 Mbit FlashROM
NV Image Memory: 256 Kbytes (mono)
Receive Buffer: 4 Kbytes
User Define Buffer: 12 Kbytes

Interface:
Dual Interface
USB V2.0 FS + Serial
USB V2.0 FS + Parallel
USB V2.0 FS + Ethernet

Environment Characteristics
Temperature:
Operating: 0 ~ 45℃ (32 ~ 113℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)

Humidity
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH



Reliability
Printer Unit (MCBF): 70 Million Lines
Thermal Print Head (TPH): 150 km
Auto Cutter: 1.8 Million Cuts

Software
Emulation: BXL / POS
Driver / Utility:
Windows Driver, OPOS Driver, JPOS Driver, Linux CUPS Driver, Mac Driver, Virtual COM USB / Ethernet Driver, Utility Program

SDK:
iOS SDK, Android SDK
Fonts / Graphics / Symbologies

Character Size:
Font A: 12 × 24 Font B: 9 × 17 Font C: 9 × 24 KOR, CHN, JPN: 24 x 24
Characters Per Line:
SRP-350III: Font A: 42 Font B, C: 56 KOR, CHN, JPN: 21

Character Sets:
Alphanumeric: 95 Extended Graphics: 128 × 37 page International: 32

Graphics:
Supporting user-defined fonts, graphics, formats, and logos

Barcode Symbologies:
1D: Codabar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, PDF417, QR code



Sensor:
Paper End, Paper Near End, Cover Open
Media Characteristics
Media Type: Receipt

Media Width:
80 mm
Optional 58 mm (with 2 inch Partition)
Media Roll Diameter: Up to 83 mm
Media Thickness: 0.062 ~ 0.075 mm
Supply Method: Easy Paper Loading

Physical Characteristics
Dimensions (WxLxD):
145 x 200 x 146 mm
(5.70 x 7.87 x 5.74 inch)
Weight: 1.56 kg (3.43 lbs)

Power:
EnergyStar Certified,
External Power Adaptor 100-240V AV, 50/60Hz

Drawer Port:
2 ports (via y-type adaptor)
Performance Characteristics
Memory: 64 Mbit SDRAM, 32 Mbit FlashROM
NV Image Memory: 768 Kbytes (mono)
Receive Buffer: 4 Kbytes
User Define Buffer: 12 Kbytes



Interface:
Standard: USB V2.0 FS + Ethernet
Optional: USB V2.0 FS + Ethernet + Serial /
Parallel / WLAN* / Bluetooth V2.1+
EDR** / Powered USB
* WLAN: 802.11b/g/n
**Bluetooth: Class 1 (100 m), MFi certified
Environment Characteristics

Temperature:
Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)

Humidity:
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RHHumidity
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH

Reliability
Printer Unit (MCBF): 70 Million Lines
Thermal Print Head (TPH): 150 km
Auto Cutter: 1.8 Million Cuts

Software
Emulation:
BXL / POS
Driver / Utility:
Windows Driver, OPOS Driver, JPOS Driver,
Linux CUPS Driver, Mac Driver,
Virtual COM USB / Ethernet Driver,



Utility Program
SDK:
iOS SDK, Android SDK, Windows SDK,
Windows Runtime SDK
Fonts / Graphics / Symbologies

Character Size:
Font A: 12 x 24 Font B: 9 x 17 Font C: 9 x 24
KOR, CHN, JPN: 24 x 24

Characters Per Line:
SRP-350plusIII: Font A: 42 Font B, C: 56
KOR, CHN, JPN: 21
SRP-352plusIII: Font A: 48 Font B, C: 64
KOR, CHN, JPN: 24

Character Sets:
Alphanumeric: 95
Extended Graphics: 128 x 33 page
International: 32

Graphics:
Supporting user-defined fonts, graphics,
formats, and logos

Barcode Symbologies:
1D: Codabar, Code 39, Code 93, Code 128,
EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, PDF417, QR code



Media Width:
80 mm
58 mm (with 2 inch Partition)
Media Roll Diameter: Up to 83 mm
Media Thickness: 0.062 ~ 0.075 mm
Supply Method: Easy Paper Loading

Physical Characteristics
Dimensions (WxLxD):
147 x 200 x 148 mm
(5.79 x 7.87 x 5.82 inch)
Weight: 1.56 kg (3.43 lbs)

Power:
EnergyStar Certified,
External Power Adaptor 100-240V AV, 50/60Hz
Drawer Port:
2 ports (via y-type adaptor)
Performance Characteristics
Memory: 128 Mbit SDRAM, 64 Mbit FlashROM
NV Image Memory: 768 Kbytes (mono)
Receive Buffer: 4 Kbytes
User Define Buffer: 12 Kbytes

Interface:
Standard: USB V2.0 FS
Optional: USB V2.0 FS + Ethernet / Serial
Dual Serial / WLAN* /
Bluetooth V4.2 Classic / LE)** /
Powered USB
* WLAN: 802.11a/b/g/n(2.4G+5G)
**Bluetooth: Class 1, MFi certified



Environment Characteristics
Temperature:
Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)

Humidity:
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH

Reliability:
Thermal Print Head (TPH)
250 km ***
Auto Cutter:
3 Million Cuts ***
*** Specified Paper
- TF50KS-E (Paper thickness: 65μm)
: Nippon Paper industries Co., Ltd.
- PD 150R (Paper thickness: 75μm)
: New Oji Paper Mfg, Co., Ltd
- PD 160R (Paper thickness: 75μm)
: New Oji Paper Mfg, Co., Ltd.
- P350 (Paper thickness: 62μm)
: Kansaki Specialty Paper, Inc. (USA)

Software
Emulation:
BXL / POS
Driver / Utility:
Windows Driver, OPOS Driver, JPOS Driver,
Linux / Mac CUPS Driver,
Virtual COM USB/Ethernet Driver, Utility Program



SDK:
iOS SDK, Android SDK, Windows SDK ,
Windows Runtime SDK
Fonts / Graphics / Symbologies

Character Size:
Font A: 12 x 24 Font B: 9 x 17 Font C: 9 x 24
KOR, CHN, JPN: 24 x 24
Characters Per Line:
SRP-380: Font A: 42 Font B, C: 56
KOR, CHN, JPN: 21
SRP-382: Font A: 48 Font B, C: 64
KOR, CHN, JPN: 24

Character Sets:
Alphanumeric: 95
Extended Graphics:128 x 35 page
International: 32
Unicode : UTF-8, UTF-16, UTF-32

Graphics:
Supporting user-defined fonts, graphics,
formats, and logos

Barcode Symbologies:
1D: Coda Bar, Code 39, Code 93, Code 128,
EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, GS1-128, GS1 DataBar Stacked /
Omnidirectional / Truncated / Limited /
Expanded, PDF417, QR code



Media Characteristics
Media Type: Receipt
Media Width: 80 / 83 mm
Media Roll Diameter: Up to 105 mm
Media Thickness: 0.062 ~ 0.075 mm
Supply Method: Easy Paper Loading

Physical Characteristics
Dimensions (WxLxD): 154 x 203 x 148 mm (6.06 x 7.99 x 5.82 inch)
Weight: 2.00 kg (4.40 lbs.)

Power:
EnergyStar Certified
External Power Adaptor 100-240V AV, 50/60Hz
Drawer Port: 2 ports (Via y-type adaptor)
Performance Characteristics
Memory: 64 Mbit SDRAM, 32 Mbit FlashROM
NV Image Memory: 768 Kbytes (Mono)
Receive Buffer: 4Kbytes
User Define Buffer: 12Kbytes

Interface:
Triple Interface:
Built-in USB V2.0 & Ethernet + Optional Serial, Parallel, Powered USB, Bluetooth or WLAN* * WLAN: 802.11b/g/n **
Bluetooth: Class 1 (100 m), MFi certified



Environment Characteristics
Temperature:
Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉)

Humidity:
Operating: 10 ~ 80% RH
Storage: 10 ~ 90% RH

Reliability
Thermal Print Head (TPH): 250 km ***
Auto Cutter: 3 Million Cuts ***
*** Specified Paper - TF50KS-E (Paper thickness: 65μm) : Nippon Paper industries Co., Ltd. -
PD 150R (Paper thickness: 75μm) : New Oji Paper Mfg, Co., Ltd - PD 160R (Paper thickness:
75μm) : New Oji Paper Mfg, Co., Ltd. - P350 (Paper thickness: 62μm) : Kansaki Specialty
Paper, Inc. (USA)

Software
Emulation:
BXL / POS
Driver:
Windows Driver, OPOS Driver, JPOS Driver, Linux / Mac CUPS Driver, Virtual COM USB/Ethernet Driver, Utility Program



SDK:
Fonts / Graphics / Symbologies
iOS SDK, Android SDK

Character Size:
Font A: 12 × 24 Font B: 9 × 17 Font C: 9 × 24 KOR, CHN, JPN: 24 x 24

Characters Per Line:
SRP-F310II: Font A: 42 Font B, C: 56 KOR, CHN, JPN: 21
SRP-F312II: Font A: 48 Font B, C: 64 KOR, CHN, JPN: 24
SRP-F313II: Font A: 53 Font B, C: 71 KOR, CHN, JPN: 26

Character Sets:
Alphanumeric: 95 Expanded
Graphics:128 × 33 page
International: 32

Graphics:
Supporting User-Defined Fonts, Graphics, Formats, and Logos
Barcode Symbologies:
1D: Coda Bar, Code39, Code93, Code128, EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, PDF417, QR Code



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
Print Color: black & orange/white & black
Size: 127*131*129mm
Weight: 1.288KG

Memory
RAM: 8MB
FLASH: 4MB

Network
with wire: TCP/IP Ethernet interface (10M/100M)
wireless: 802.11 b/g/n, BT4.0 BLE(Optional)
NFC: Optional(only support Wireless)

Print
Printing Method: Thermal line/Support QR code Printing
Printing setup: Support header margin adjustment, support line spacing, the width of the receipt, barcode height adjustment
Printing Width: 72mm
Resolution: 203dpi
Printing Speed: 250mm/s
Paper Width: 80mm(compatible with 58 paper)
Paper compartment Capacity: 80mm
Cutter: Support(support paper back when finish cutting, Support pull function)



Outside interface
Cash Drawer: 1xRJ11
1xUSB Standard/ethernet
Key: Power Key/Cover key/Feed Key
Light: Monochromatic lamp support
Voice
Buzzer: Support
Suona: Voice Alarm
Power Adapter: 24V/2.5A
Compatible Supported System: XP,Win7,Win8,Win10,ios, Android,Linux,MacOS

Language
Display language: Support most languages, individual language to be customized
Printing language: Support most languages, individual language to be customized
Packaging/accessories:    USB data line - power line adapter - - warranty card - Driver CD - Certificate - quick installation guide

Packaging
■ Color box or kraft
■ Pearl cotton paper tray
Environment
Temperature:    Storage:-20~70℃/ working temperature: 0℃-40℃
Humidity: Storage humidity:5%—95% /working temperature humidity:20%—85%



ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
RAM: 8MB
FLASH: 4MB
Display: OLED single color - Blue
Paper cutting method
Αuto cutter: N/A
Cutter: support
Printing
Printing Method: Thermal Line
Effective Printing Width: 72mm
Resolution: 203dpi
Printing speed: 90mm/s(Max)
Paper width: Max -> 80mm
Label height: Min-> 20mm/Max -> 300mm
Paper warehouse capacity: 50mm
Interface
1x Standard Mircro USB



Bluetooth
WiFi
Power supply: DC connector 3 .5*1.5
Sound: Beeper
Power supplier: Adapter    8.5V 1A
Compatibility Support: XP,Win7,Win8,Win10,ios, Android, Linux
Functionality
Support all kinds of intelligent terminals,PDA printing
Support one dimensional code, QR CODE, image,and curve printing
Compatible with black label paper, Sewing paper，continuous paper，linerless paper
Support burton Function
Environment
Temperature: Working: 0℃—40, Storage: -20 ℃—70℃
Humidity: Working : 2 0%—85% ; Storage: 5% —95%



ENVIRONMENTAL
Charging Temperature:
0°C to 40°C (32°F to 104°F)

Drop Spec:
1.2 m (4 ft) drop to concrete per MIL STD 810G, 1.5 m (5 ft) multiple drops to concrete with optional environmental case.
Rain and Dust Resistance:
IP42, IP54 with optional environmental case
Humidity:

Operating humidity: 20% to 85% non-condensing Stprage humidity: 5% to 95% non-condensing

Operating Temperature
-10°C to 50°C (14°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F) without battery

MEMORY
RAM Memory: 16 MB
Flash ROM: 64 MB

POWER
AC Adapter:
100 to 240 VAC 10VDC@1.0A; meets CEC EPS

Battery Type:
Standard Battery: Rechargeable, removable, 7.4V Li-Ion, 1620mAh
Smart Battery: Rechargeable, removable, 7.4V Li-Ion, 1620mAh.
Includes integrated fuel gauge to monitor battery charge levels, and report impedance and list battery pack serial number for the battery in use.

Endurance Per Fully Charged Battery:
Endurance per fully charged battery at 6% print density: PR2: 118 m (387 ft); PR3: 89 m (292 ft)

Recharging Time:
approximately 240 minutes



PRINT SPECIFICATIONS
Media Type:
Receipt media
Max Print Width:
PR2: 48 mm (1.89 in)
PR3: 72 mm (2.83 in)

Max Width:
PR2: 57 mm to 58 mm (2.244 in to 2.283 in)
PB3: 79 mm to 80 mm (3.110 in to 3.149 in)

Print Speed:
203 dpi (8 dots/mm)
PR2: Up to 3 ips (76.2 mm/sec)
PR3: Up to 3 ips (76.2 mm/sec)

Print Technology:
Label Roll Max Diameter:
PR2: 1.6 in (40.64 mm)
PR3: 1.6 in (40.64 mm)

Label Roll Core:
Core ID: 10 mm (0.4 in)

Thickness:
60 μm to 100 μm (2.36 mils to 4 mils)

Length:
Continuous

Printhead:
Direct thermal

COMMUNICATIONS INTERFACE
Standard:
USB full speed V2.0

Optional:
Bluetooth (2.1, Class II), Bluetooth for iOS (2.1+EDR), Made for iPod/iPhone/iPad™ certified, NFC Technology for easy Bluetooth pairing

Graphics:
Supports user-defined fonts, graphics, including custom logos



SOFTWARE
Programming Language:
ESC/P (Line Print and Easy Print modes), CSim (CPCL) and XSim (Ex-PCL)
• Honeywell PrintSet Configuration Utility
• Bartender Ultralite Labeling Software
• SmartSystems Foundation Console/Server Software
• Bootloader Utility
• SDKs for Android, Apple iOS and Windows Mobile
• InterDriver Printer Drivers for Microsoft Windows PCs

SUPPORTED BARCODE SYMBOLOGIES
ESC/P:
1D: Codabar, Code 39, Code 128, UCC/ EAN-128, Interleaved 2 of 5, UPC-A, EAN13, EAN8
2D:Aztek, PDF417, QR Code

CSim (CPCL):
1D: Codabar, Code 39, Code 128, UCC/ EAN-128, Interleaved 2 of 5, UPC-A, UPC-E, EAN13, EAN8
XSim (Ex-PCL):
1D: Codabar, Code 39, Code 128 Subset A-C, UCC/ EAN-128, Interleaved 2 of 5, UPC/EAN/JAN 2D: PDF417

ACCESSORIES
Factory/Service Installable
• Belt loop
• Metal belt clip
• Shoulder strap
• IP54 protective environmental case
• Protective boot
• Printhead cleaning swab
• Spare battery
• Cigarette lighter adapter/12V vehicle battery charger
• FlexDock Modular docking system for on-board charging or spare battery charging

Optional:
Card Reader:
• Magnetic Stripe Reader (MSR) 3 track
• ANSI/ISO 7810, 7811 standards
• AAMVA, CA DVA, RAW
Optional support for DES, TDES, and AES encryption with DUKPT key management.

POWER
Battery Type/Supply
PB22:Battery Type/Supply: 7.2V Li-Ion, 2.25 Ah, rechargeable battery
PB32: 7.2V Li-Ion, 2.25 Ah, rechargeable battery
PB50:14.8V Li-Ion, 2.2 Ah, rechargeable battery

PRINT SPECIFICATIONS
Resolution
PB22:203 dpi (8 dots/mm)
PB32:203 dpi (8 dots/mm)
PB50:203 dpi (8 dots/mm)

Print Speed
PB22:4ips (101.6mm/sec)
PB32:4ips (101.6mm/sec)
PB50:4ips (101.6mm/sec)

Max Print Width
PB22: 55.88 mm (2.2 in)
PB32: 72 mm (2.8 in)
PB50: 111.5 mm (4.39 in)

Print Technology
PB22:Direct thermal
PB32:Direct thermal
PB50:Direct thermal



ENVIRONMENTAL
Operating Temperature
PB22: -15°C to 50°C (5°F to 122°F)
PB32: -15°C to 50°C (5°F to 122°F)
PB50: -15°C to 50°C (5°F to 122°F)

Storage Temperature
PB22: -30°C to 70°C (-22°F to 158°F)
PB32: -30°C to 70°C (-22°F to 158°F)
PB50: -30°C to 70°C (-22°F to 158°F)

Humidity
PB22:10 to 90% (non-condensing)
PB32:10 to 90% (non-condensing)

Drop Survival
PB22:1.5 m (5 ft) drops to concrete; 26 times including all corners and sides (Mil Std 810F procedure) 2 m (6.5 ft) multiple drops to concrete with optional protective case
PB32:1.5 m (5 ft) drops to concrete; 26 times including all corners and sides (Mil Std 810F procedure) 2 m (6.5 ft) multiple drops to concrete with optional protective case
PB50: 1.5 m (5 ft) drops to concrete; 26 times including all corners and sides



MEDIA
Max. Media Diameter: 127.0 mm (5.0 in)
Media Core Sizes: 25.4 mm (1.0 in), 38.1 mm (1.5 in)
Media Width: 25.4 mm (1.0 in) to 110 mm (4.3 in)
Min. Label Length: 9.6 mm (0.3 in)

RIBBON
Ribbon Support: Coated Side Out
Max. Ribbon Diameter: 68.0 mm (2.7 in)
Ribbon Core Sizes: 12.7 mm (0.5 in), 25.4 mm (1.0 in)
Ribbon Width: 25.4 mm (1.0 in) to 109.2 mm (4.3 in)
Max. Ribbon Length: 25.4 mm (1.0 in) core: 300.0 m (984.0 ft), 12.7 mm (0.5 in) core: 75.0 m (246.0 ft)

PRINTING
Print Resolution: 8.0 dpmm (203 dpi)
Max. Print Speed: 101.6 mm/s (4.0 ips)
Max. Print Width: 104.1 mm (4.1 in)

COMMUNICATIONS
Standard Interfaces: USB Device, USB Host
Options:
Factory Installed: Internal Ethernet, serial port
Protocols:
Network: TCP/IP-suite (TCP, UDP, ICMP, IGMP), DHCP, BOOTP, LPR, FTP, web page and
Telnet 9100, IPv4 Serial Flow Control: XON/XOFF, RTS/CTS



USER INTERFACE
Display: 1 Feed Button and LED Display
Web Page Languages:
English and Simplified Chinese (Default), Spanish, Portuguese, Russian, Korean, Japanese, Thai

GRAPHICS & BAR CODES
Native Graphic Formats: 1-bit BMP, GIF, PCX, PNG
Barcode Symbologies:
All major 1D and 2D symbologies are supported, including Aztec, Code 16K, Code 49, Data Matrix, Dot Code, EAN-8, EAN-13, EAN, UCC 128, Grid Matrix, HIBC 39, HIBC 128, MaxiCode, MSI (modified Plessey), PDF417, Micro PDF417, Planet, Plessey, Postnet, QR-Code, RSS-14 (variations)

SOFTWARE
Printer Command Languages: Direct Protocol (DP), ZSim (ZPL II®), ESim (EPL)
Drivers: BarTender®, InterDriver Windows® Printer Driver
Character Sets:
English & Extended Latin, Arabic, Baltic & Baltic Rim, Cyrillic, Greek, Hebrew, Thai, Turkish, Vietnamese, & more with Monotype™ Universal Font Scaling Technology (UFST) & WorldType Layout Engine (WTLE)

ENVIRONMENTAL
Operating Temperature: +5°C to +40°C (+41°F to +104°F) 10 to 80% RH non-condensing
Storage Temperature: -40°C to +60°C (-40°F to +140°F) @ 10 to 90% RH



ELECTRICAL
Input: 100-240V AC @ 50-60 Hz, 1.5 A
Output: 24V DC, 2.5 A

MEMORY
Standard: 64 MB Flash, 64 MB SDRAM
Optional: Up to 32 GB (via user-supplied USB thumb drive) formatted as FAT16 or FAT32v OPTIONS
Factory Installable: Ethernet, serial port

APPROVALS
Regulatory: UL, cUL, cULus, CE, FCC Class A, D Mark CCC, KCC, RCM
Safety:
North America: UL & cUL Listed, UL 60950-1 Europe: D Mark, EN 60950-1; CE Mexico: NYCE Certified, NOM 19 Other Countries: IEC 60950-1
EMC:
USA FCC Title 47, Part 15, Subpart A, Class A; Europe EMC Directive (EN55022 Class A + EN55024); CISPR22



Ports & interfaces
Ethernet LAN:    Yes
Wi-Fi: No
Optional connectivity: Wireless LAN
Connectivity technology:    Wired
USB 2.0 ports quantity: 2
RS-232 ports: 1

Memory
Internal memory: 64 MB
Flash memory: 128 MB

Paper handling
Maximum roll diameter: 130 mm
Media thickness: 0.06-0.20 mm
Supported paper width: 20-110 mm
Core diameter: 12.5 mm

Performance
Built-in barcodes: 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 128 (A/B/C),Code 39,Code 49,Code 93,Data Matrix,EAN13,EAN8,GS1 DataBar,IMB,Industrial 2/5,Interleaved 2/5,MaxiCode,MicroPDF417,PDF417,POSTNET,QR Code,TLC39,UPC-A,UPC-E
Ribbon length: 74 m
Ribbon width: 110 mm



Power
Energy Star certified: Yes
Input voltage: 100-240 V
Input frequency: 50 - 60 Hz

Weight & dimensions
Width: 200 mm
Depth: 252 mm
Height: 173 mm
Weight: 2350 g

Operational conditions
Operating relative humidity (H-H): 10 - 80 %
Storage relative humidity (H-H): 10 - 90 %
Operating temperature (T-T): 5-40 °C
Storage temperature (T-T): -20-60 °C

Other features
Emulations: SLCS,BPL-Z,BPL-E
